Top 10 Battery Operated Stacker Manufacturers in Ahmedabad, Gujarat, India
Contilift Equipment is one of the leading Battery Operated Stacker Manufacturers, Suppliers, Dealers and Exporters serving Ahmedabad, Gujarat. We offer reliable material-handling solutions for warehouses, manufacturing plants, logistics facilities, engineering units, and other industrial applications. With our manufacturing facility in Pune, we supply high-quality battery-operated stackers to customers in Ahmedabad and across Gujarat.
Our range includes 1500 kg and 2000 kg battery-operated stackers with lifting heights of up to 6500 mm, depending on the model. Designed for lifting, transporting, positioning, and stacking palletized loads, our stackers help improve material-handling efficiency and reduce manual handling requirements. We offer different configurations based on load capacity, lifting height, battery type, pallet dimensions, available operating space, and specific industrial requirements.
At a glance: 1500 & 2000 kg | lift up to 6500 mm | 24V lithium-ion or lead-acid | cold-store model (-20°C) | die loader & counterbalance
Last updated: 7 October 2026
What is a Battery Operated Stacker?
A battery-operated stacker is an electrically powered material-handling machine used to lift, move, and stack pallets and other industrial loads. A rechargeable battery supplies power to the machine's lifting and operating systems, allowing loads to be positioned with less manual effort.
Battery-operated stackers are commonly used in warehouses, manufacturing units, distribution centres, storage facilities, and industrial plants where palletized materials need to be moved and stacked efficiently.
The required stacker depends on factors such as:
- Load capacity
- Lifting height
- Pallet dimensions
- Load centre
- Fork length
- Battery type
- Operating hours
- Aisle width
- Floor conditions
- Application requirements
Types of Battery Operated Stackers
Contilift Equipment offers different battery-operated stacker configurations for pallet handling, warehouse storage, truck loading, die handling, and specialized industrial applications. Each type is described below with its technical specifications.
Battery Operated Stacker – 2000 Kg
Lifting Height: 6000 mm
| Capacity | 2000 Kg |
|---|---|
| Lifting Height | 6000 mm |
| Fork Length | 1150 mm |
| Battery | Lithium Ion 24V |
| Charger | 24V |
| Controller | Curtis |
| Wheel | Polyurethane |
Battery Operated Stacker – 2000 Kg
Lifting Height: 3500 / 6500 mm
| Capacity | 2000 Kg |
|---|---|
| Lifting Height | 3500 / 6500 mm |
| Fork Length | 1150 mm |
| Battery | Lithium Ion 24V |
| Controller | Curtis |
| Wheel | Polyurethane |
Battery Operated Counter Balance Stacker – 2000 Kg
Lifting Height: 4300 mm
| Capacity | 2000 Kg |
|---|---|
| Lifting Height | 4300 mm |
| Fork Length | 1150 mm |
| Battery | Lithium Ion 24V |
| Charger | 24V |
| Wheel | Polyurethane |
Battery Operated Stacker – 1500 Kg
Lifting Height: 1200 mm
| Capacity | 1500 Kg |
|---|---|
| Lifting Height | 1200 mm |
| Fork Length | 1150 mm |
| Working Temperature | -20°C |
| Battery | 24V Lead Acid (Exide) |
| Charger | 24V |
Battery Operated Die Loader Stacker – 2000 Kg
Lifting Height: 1200 mm
| Capacity | 2000 Kg |
|---|---|
| Roller Bed Size | 1200 × 1200 mm |
| Overall Size | 2400 × 1150 mm |
| Overall Height | 2550 mm |
| Lifting Height | 1200 mm |
| Battery | Lithium Ion 24V |
| Wheel | Polyurethane |
| Power Pack | 3 kW |
Contilift Equipment also manufactures special-purpose battery-operated stackers for applications requiring customized dimensions, handling arrangements, or other non-standard specifications.
Battery Operated Stackers at a Glance
| Model | Capacity | Lifting Height | Battery | Best For |
|---|---|---|---|---|
| Battery Operated Stacker | 2000 Kg | 6000 mm | Lithium-ion 24V | High-level pallet storage |
| Battery Operated Stacker | 2000 Kg | 3500 / 6500 mm | Lithium-ion 24V | High-level pallet storage with a choice of lifting heights |
| Counter Balance Stacker | 2000 Kg | 4300 mm | Lithium-ion 24V | Truck loading, unloading and material transfer |
| Battery Operated Stacker | 1500 Kg | 1200 mm | Lead-acid 24V (Exide) | Cold-store handling (-20°C) |
| Die Loader Stacker | 2000 Kg | 1200 mm | Lithium-ion 24V | Die and mould handling |
Technical Specifications of Battery Operated Stackers
Contilift Equipment offers battery-operated stackers in different load capacities, lifting heights and configurations for warehouse storage, pallet handling, production areas and specialised die-handling applications. The following specifications help you compare each model and select the suitable stacker for your requirement.
| Battery Operated Stacker Type | Capacity | Lifting Height | Fork / Roller Specification | Battery | Controller / Power | Wheel | Overall / Key Dimensions | Suitable Applications | Why It Is Suitable |
|---|---|---|---|---|---|---|---|---|---|
| Battery Operated Stacker – 2000 Kg / 6000 mm | 2000 Kg | 6000 mm | Fork Length: 1150 mm | Lithium Ion, 24V | Curtis Controller | Polyurethane | — | High-level warehouse storage, pallet stacking, rack loading, material storage | The 6000 mm lifting height allows pallets to be placed at higher rack levels, while the 2000 Kg capacity supports handling of heavy industrial loads. It is suitable where both high lifting and substantial load capacity are required. |
| Battery Operated Stacker – 2000 Kg / 3500–6500 mm | 2000 Kg | 3500 / 6500 mm | Fork Length: 1150 mm | Lithium Ion, 24V | Curtis Controller | Polyurethane | — | Warehouses, distribution centres, pallet stacking, multi-level storage, loading and unloading | The available 3500 mm and 6500 mm lifting options provide flexibility for different storage heights. It is suitable when the required lifting height varies between applications or rack configurations. |
| Battery Operated Counter Balance Stacker – 2000 Kg | 2000 Kg | 4300 mm | Fork Length: 1150 mm | Lithium Ion, 24V | Curtis Controller | Polyurethane | — | Pallet handling, production areas, warehouse movement, loading/unloading, applications requiring counterbalance operation | The counterbalance configuration helps handle loads without depending on the same type of support arrangement as conventional stackers. Its 4300 mm lifting height and 2000 Kg capacity make it suitable for general industrial pallet handling and storage. |
| Battery Operated Stacker – 1500 Kg | 1500 Kg | 1200 mm | Fork Length: 1150 mm | 24V Lead Acid (Exide) | 24V Charger | — | — | Low-level pallet handling, short-distance material movement, floor-level stacking, warehouses and production areas | The 1500 Kg capacity and 1200 mm lifting height make this model suitable when very high rack lifting is not required. It can be considered for routine pallet movement and low-level lifting applications. The stated working temperature is -20°C. |
| Battery Operated Die Loader Stacker – 2000 Kg | 2000 Kg | 1200 mm | Roller Bed: 1200 × 1200 mm | Lithium Ion, 24V | Power Pack: 3 kW | Polyurethane | Overall: 2400 × 1150 mm; Overall Height: 2550 mm | Die loading, die changing, mould handling, press-machine loading and industrial tooling applications | The 1200 × 1200 mm roller bed is designed for handling dies and tooling rather than conventional pallet-only applications. The 2000 Kg capacity, 1200 mm lift and 3 kW power pack make it suitable for positioning heavy dies at machine or press working levels. |
How Does a Battery Operated Stacker Work?
A battery-operated stacker uses an electric power system and lifting mechanism to move and raise loads.
- Fork Positioning: The operator positions the forks correctly beneath the pallet or load.
- Load Engagement: The forks are inserted into the pallet openings and positioned to maintain suitable load balance.
- Electric Lifting: The powered lifting mechanism raises the load to the required height.
- Load Transportation: The machine moves the pallet to the designated storage, production, or loading area.
- Load Positioning: The operator aligns the pallet with the required location.
- Controlled Lowering: The load is lowered to the required position before the forks are withdrawn.
Operators should always follow the machine's operating instructions and applicable workplace safety procedures.
Key Features and Benefits of Battery Operated Stackers
Battery-operated stackers are available in different configurations to support controlled material handling, pallet storage, die handling, and specialized industrial applications, while reducing the physical effort involved in moving loads.
- Less Manual Handling: Battery-powered lifting reduces repetitive effort and supports smoother day-to-day pallet movement.
- Better Use of Storage Height: Selected configurations offer lifting heights up to 6500 mm for high-level pallet storage.
- Multiple Load Capacities: Available configurations include 1500 kg and 2000 kg load capacities to suit different handling requirements.
- Lithium-Ion and Lead-Acid Options: Battery configurations include 24V Lithium-Ion and 24V Lead Acid systems.
- Counterbalance Configuration: Rear counterweight designs provide an alternative to conventional front-support arrangements for suitable loading and unloading applications.
- Compact Handling: Compact configurations support material movement where floor space and manoeuvrability are important.
- Die Handling Capability: Die loader configurations feature a 1200 × 1200 mm roller bed for handling and positioning dies and moulds.
- Application-Specific Configurations: Special-purpose stackers can be customized for specific load dimensions, lifting requirements and handling conditions.
- Industrial-Grade Components: Configurations can include Curtis controllers, polyurethane wheels, 24V chargers and 3 kW power packs, depending on the model.
- Cold-Store Operation: The specified 1500 kg configuration can operate in cold-store conditions down to -20°C.
How to Select the Right Battery Operated Stacker
Choosing the correct stacker requires more than simply selecting the highest available capacity. The equipment should match the actual working conditions.
- Load Capacity: Identify the maximum load weight that will be handled. The rated capacity of the machine should be suitable for the intended load and operating conditions.
- Lifting Height: Determine the required rack or storage height before selecting the lifting configuration.
- Pallet and Load Dimensions: Pallet dimensions, fork length, load centre, and load shape affect the suitability of the stacker.
- Aisle and Operating Space: Check aisle width, turning space, access points, and floor conditions before finalizing the equipment.
- Battery Requirements: Battery type and operating capacity should be selected according to usage frequency, operating hours, charging arrangements, and working environment.
- Application: Warehouse stacking, manufacturing material movement, truck loading, cold storage, die handling, and other applications may require different stacker configurations.
Example: measure the height of the highest rack beam where a pallet will rest, then allow for pallet height and working clearance. If the top beam is at 4000 mm, a 4300 mm configuration may be the minimum to consider; our team will confirm the exact clearance you need.
Capacity at height: rated capacity applies at a specified load centre. It can reduce at greater lifting heights or with long or off-centre loads, so ask us for the capacity-at-height details of your chosen model.
Battery Operated, Semi-Electric and Manual Stackers: What's the Difference?
Buyers use these terms differently, so please confirm exactly what you need. The table shows the general difference between lifting and travel mechanisms; our team will confirm the drive type of the model you choose.
| Stacker Type | Lifting Mechanism | Travel / Movement | Typical Capacity / Lift | Best Suited For | Why Choose It? |
|---|---|---|---|---|---|
| Manual Stacker | Hand pump / manual hydraulic lifting | Pushed by hand | Generally suited to lighter or occasional handling requirements | Small warehouses, workshops, maintenance areas, occasional pallet handling and short-distance movement. See wide-leg manual stackers and manual boom stackers. | Simple operation and suitable when lifting frequency and travel distance are limited. It can be considered where powered travel is not necessary. |
| Semi-Electric Stacker | Electric lifting | Pushed by hand | Suitable for regular lifting where powered lifting is preferred | Warehouses, production areas, short-distance pallet movement and regular stacking. See semi-electric stackers. | Electric lifting reduces manual pumping effort while manual travel keeps the equipment suitable for applications involving shorter movement distances. |
| Fully Battery Operated Stacker | Electric lifting | Electric drive | Suitable for frequent material handling and higher-duty applications; model-dependent | Warehouses, distribution centres, production facilities, pallet stacking, rack storage and repeated material movement. See battery operated electric stackers. | Electric lifting and travel reduce manual handling effort and make the equipment more suitable for frequent lifting and longer travel distances. |
Lithium-Ion vs Lead-Acid Batteries
Our models are offered with 24V lithium-ion or 24V lead-acid batteries, depending on the model.
| Point | Lithium-Ion | Lead-Acid |
|---|---|---|
| Upfront cost | Generally higher | Generally lower |
| Charging | Generally faster; suits short top-ups between shifts | Generally slower; plan full charge cycles |
| Maintenance | Generally lower | Depends on battery type; follow the maker's care instructions |
| Best when | Usage is frequent or multi-shift | Usage is lighter or budget is tight |
Applications of Battery Operated Stackers
Battery-operated stackers are used for lifting, stacking, transporting, and positioning materials across warehouses, manufacturing facilities, logistics operations, and specialized industrial environments.
- Warehouse Material Handling and High-Level Pallet Storage: Moving and stacking palletized goods and placing pallets at elevated rack levels. Consider the 2000 kg models with 3500 to 6500 mm lift.
- Manufacturing Plants: Used to transfer raw materials, components, finished products, and production loads between different work areas.
- Loading and Unloading: Truck loading, unloading, and material transfer where conventional front support legs may not be suitable. Consider the counterbalance stacker.
- Production and Assembly Areas: Compact electric stackers can assist with moving materials around production lines, assembly stations, and other space-constrained work areas.
- Die and Mould Handling: Die loader stackers with roller-bed platforms lift, move, and position heavy dies and moulds in press shops, tool rooms, and engineering units.
- Cold-Store Operations: Low-temperature storage environments, including applications down to -20°C. Consider the 1500 kg model.
- Logistics and Distribution: Pallet movement, order handling, staging, and internal transportation in logistics facilities.
- Specialized Industrial Handling: Customized stacker configurations can be developed for loads with specific dimensions, weights, lifting heights, or handling requirements.
Supply and Service for Ahmedabad and Gujarat
Contilift Equipment's office and works are in Bhosari, Pune, Maharashtra (see our manufacturing facility). We supply battery-operated stackers to Ahmedabad and other locations in Gujarat, subject to product availability. Delivery timing, installation support and after-sales terms for your site are confirmed in the quotation. Share your plant location and requirement and we will advise on delivery.
Price Factors and How to Request a Quote
Stacker price depends on capacity, lifting height, battery type, controller and power pack, customization, and quantity. For an accurate quotation, please send us:
- Load weight and pallet size
- Rack height or required lifting height
- Aisle width and floor condition
- Shifts per day and battery preference
- Application (warehouse, truck loading, dies, cold store)
Safe Operation and Battery Care
- Use trained operators and never exceed the rated capacity.
- Check forks, mast, wheels and controls before each shift.
- Travel with the load low and keep clear of people.
- Charge in a suitable, ventilated area and follow the battery maker's instructions.
Why Choose Contilift Equipment?
Contilift Equipment provides battery-operated stacker solutions designed around different load capacities, lifting requirements, operating conditions, and material-handling applications.
- Product Range: We offer multiple battery-operated stacker configurations, including 1500 kg and 2000 kg models with different lifting heights.
- Application-Based Selection: Equipment can be selected according to the load, lifting height, pallet dimensions, operating space, and intended application.
- Special-Purpose Solutions: We provide special-purpose battery-operated stacker configurations for applications where standard models may not meet specific requirements.
- Industrial Material Handling Focus: Our stackers are designed for applications across warehouses, manufacturing facilities, logistics operations, engineering units, automotive industries, and other industrial environments.
- Technical Assistance: Customers can discuss their material-handling requirements with our team before selecting a suitable configuration.
- Service and Support: We assist customers with product-related requirements and technical information to help them select equipment suitable for their intended application.
Get the Right Battery Operated Stacker for Your Application
Contilift Equipment is a Battery Operated Stacker Manufacturers, Suppliers, Dealers and Exporters in Ahmedabad offering 1500 kg and 2000 kg stackers with different lifting heights and application-specific options for Ahmedabad and across Gujarat. Each stacker can be selected according to your load capacity, lifting height, pallet dimensions, fork requirements, operating space, battery type, working environment, and application. Share your requirements with our team to discuss a suitable configuration, get detailed product information, and request a quotation.
Frequently Asked Questions
A battery-operated stacker is an electrically powered material-handling machine used for lifting, moving, positioning, and stacking palletized loads. It uses a rechargeable battery to operate its powered functions.
Contilift Equipment offers battery-operated stacker configurations including 1500 kg and 2000 kg models. The appropriate capacity depends on the customer's load-handling requirements.
Selected Contilift battery-operated stacker models provide lifting heights of up to 6500 mm. The actual lifting height depends on the model and configuration.
Battery type depends on the model. Available configurations include 24V Lithium-Ion and 24V Lead Acid battery systems.
Price depends on capacity, lifting height, battery type, machine configuration, specifications, customization, and quantity. Contact Contilift Equipment for a quotation based on your requirements.
Share the load weight, pallet size, required lifting height or rack height, aisle width, shifts per day, battery preference, floor condition and application.
Manual stackers are lifted and moved by hand. Semi-electric stackers generally use electric lifting with manual travel. Fully electric stackers use electric lifting and electric travel. Tell us which you need and we will confirm the matching model.
Yes. Contilift Equipment manufactures special-purpose battery-operated stackers for selected applications requiring customized dimensions, handling arrangements, or other specific requirements.
They are used in warehouses, manufacturing plants, logistics facilities, engineering units, automotive industries, packaging operations, cold storage, and other material-handling environments.
Consider the maximum load, lifting height, pallet size, load centre, fork length, aisle width, operating hours, battery requirement, floor conditions, and application before selecting the equipment.
Yes. Our office and works are in Bhosari, Pune, and we supply battery-operated stackers to Ahmedabad and other locations in Gujarat, subject to product availability and delivery requirements.
Yes. Special-purpose battery-operated stacker configurations can be considered for applications involving dies, moulds, specific load dimensions, or other specialized material-handling requirements.
Get a Quote for a Battery Operated Stacker
Share your required capacity, lifting height, pallet dimensions, application, and operating conditions with Contilift Equipment. Our team can help you identify a suitable stacker configuration and provide the required product details and quotation for Ahmedabad and Gujarat.
