Top 10 Scissor Lift Manufacturers in Ahmedabad, Suppliers and Dealers in Ahmedabad
Contilift Equipments is a Scissor Lift Manufacturers, Suppliers and Dealers in Ahmedabad, offering industrial lifting solutions for material handling, loading, unloading, die handling, maintenance, and vertical material transfer applications. Our scissor lifts are designed for different load capacities, platform sizes, lifting heights, and installation requirements to suit diverse industrial environments.
Our range includes Pit Mounted Scissor Lift, Die Roller Scissor Lift, Semi Electric Mobile Scissor Lift, Mobile Scissor Lift, and Floor Mounted Scissor Lift. Available models range from 800 Kg to 2000 Kg capacity, with different configurations for fixed and mobile lifting applications.
Types of Scissor Lift
Contilift Equipments provides different types of Scissor Lifts for industrial lifting and material handling requirements. Each type is designed according to its installation arrangement, mobility, load capacity, platform configuration, and intended application.
- Pit Mounted Scissor Lift: Pit Mounted Scissor Lifts are installed inside a prepared floor pit so that the platform can reach a low position close to floor level. This configuration is suitable for loading docks, pallet transfer, warehouses, and floor-to-floor material movement. Contilift offers 1000 Kg and 2000 Kg Pit Mounted Scissor Lift models, with lifting heights up to 2350 mm.
- Die Roller Scissor Lift: Die Roller Scissor Lifts are designed for press shops, tool rooms, and die-handling applications. A roller platform allows heavy dies and moulds to be moved more conveniently during machine loading, unloading, and positioning. Contilift's 1000 Kg Die Roller Scissor Lift has a 1440 × 800 mm platform, 1000 mm lifting height, and 500 mm lowered height.
- Semi Electric Mobile Scissor Lift: Semi Electric Mobile Scissor Lifts combine mobile movement with electrically powered lifting. They are suitable for applications where the lift needs to be repositioned within a facility while reducing the manual effort required for lifting. Contilift's 1000 Kg Semi Electric Mobile Scissor Lift features nylon wheels, a 12V Exide battery, 12V charger, and 900 mm lifting height.
- Mobile Scissor Lift: Mobile Scissor Lifts are designed for applications where lifting equipment needs to be moved between suitable work areas. Contilift offers 800 Kg and 1500 Kg Mobile Scissor Lift models with different platform dimensions and lifting heights. These lifts can be used for maintenance, material handling, workshops, production areas, and other applications requiring repositionable lifting equipment.
- Floor Mounted Scissor Lift: Floor Mounted Scissor Lifts are fixed lifting systems installed directly on the floor for repeated material handling and height adjustment operations. Contilift's 1000 Kg Floor Mounted Scissor Lift has a 1500 × 1200 mm platform, 1200 mm lifting height, 550 mm lowered height, 1 HP power pack, three-phase control panel, and manual lip plate.
2000 Kg
Pit Mounted Scissor Lift – 2000 Kg
Installed flush into a floor pit for a low, obstruction-free approach, this 2000 Kg lift is built for loading docks and heavy pallet transfer between floor levels with a large 3000 × 2350 mm platform.
- Capacity: 2000 Kg
- Lifting Height: 2350 mm
- Platform Size: 3000 × 2350 mm
- Power Pack: 1 HP
- Control Panel: 3 Phase
1000 Kg
Die Roller Scissor Lift – 1000 Kg
Fitted with a roller top for sliding heavy dies and moulds into position, this compact 1000 Kg lift is built for press shops and tool rooms that need precise, low-height die changing.
- Capacity: 1000 Kg
- Platform Size: 1440 × 800 mm
- Lifting Height: 1000 mm
- Lowered Height: 500 mm
1000 Kg
Semi Electric Mobile Scissor Lift – 1000 Kg
A battery-assisted mobile lift on nylon wheels, this 1000 Kg model combines manual mobility with electric lifting for quick, repositionable elevated access around the facility.
- Capacity: 1000 Kg
- Platform Size: 900 × 600 × 50 mm
- Lifting Height: 900 mm
- Wheel Type: Nylon
- Battery: 12V Exide
- Charger: 12V
800 Kg
Mobile Scissor Lift – 800 Kg
A lightweight, easily repositioned lift on 2 fixed and 2 swivel wheels, ideal for maintenance, installation, and light-duty elevated access tasks around indoor work areas.
- Capacity: 800 Kg
- Platform Size: 1200 × 600 mm
- Lifting Height: 1500 mm
- Fixed Wheels: 2 Nos
- Swivel Wheels: 2 Nos
1000 Kg
Floor Mounted Scissor Lift – 1000 Kg
A fixed, permanently installed stationary lift with a manual lip plate for bridging the loading gap, built for repeated dock-height leveling and material transfer in warehouses.
- Capacity: 1000 Kg
- Platform Size: 1500 × 1200 mm
- Lifting Height: 1200 mm
- Lowered Height: 550 mm
- Power Pack: 1 HP
- Control Panel: 3 Phase
- Lip Plate: 1 No. Manual
1500 Kg
Mobile Scissor Lift – 1500 Kg
A higher-capacity mobile lift with a wider 1300 × 1300 mm platform and 3-phase power pack, suited for heavier loads that still need to be moved between work areas.
- Capacity: 1500 Kg
- Platform Size: 1300 × 1300 mm
- Lifting Height: 1200 mm
- Wheel Type: Nylon
- Power Pack: 3 Phase
- Control Panel: 3 Phase
1000 Kg
Pit Mounted Scissor Lift – 1000 Kg
A compact pit-mounted lift with a 1800 mm lifting height and low 300 mm lowered height, suited for facilities needing a flush, space-saving elevated platform at a smaller capacity.
- Capacity: 1000 Kg
- Platform Size: 1200 × 1200 mm
- Lifting Height: 1800 mm
- Lowered Ht: 300 mm
Technical Specifications of Scissor Lift
Contilift Equipments offers different types of scissor lifts for industrial lifting, material handling, warehouse operations, die changing, and production applications. The following technical comparison covers seven scissor lift models, including rated load capacity, platform dimensions, lifting height, lowered height, installation arrangement, power system, mobility components, and primary industrial applications.
| Sr. No. | Scissor Lift Type / Model | Rated Load Capacity | Platform Dimensions (L × W) | Maximum Lifting Height | Lowered Height | Installation / Mobility | Drive / Power System | Platform Configuration | Wheels / Mobility Components | Control / Electrical Details | Primary Industrial Applications | Key Technical Characteristics |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Pit Mounted Scissor Lift – 2000 kg | 2000 kg (2 tonnes) | 3000 × 2350 mm | 2350 mm | Not specified | Fixed installation inside a prepared floor pit | Hydraulic power pack; 1 HP | Large, flat load-bearing platform | Not specified | Three-phase control panel | Loading docks, heavy pallet transfer, warehouse logistics, floor-to-floor material movement | High-capacity platform with a flush-floor approach; suitable for handling bulky loads and transferring materials between different floor elevations |
| 2 | Pit Mounted Scissor Lift – 1000 kg | 1000 kg (1 tonne) | 1200 × 1200 mm | 1800 mm | 300 mm | Fixed, pit-mounted installation | Not specified | Compact, square platform | Not specified | Not specified | Warehouses, pallet loading, production lines, floor-level material transfer | Compact installation footprint with a low 300 mm lowered height and an 1800 mm lifting stroke |
| 3 | Die Roller Scissor Lift – 1000 kg | 1000 kg (1 tonne) | 1440 × 800 mm | 1000 mm | 500 mm | Typically fixed at a designated die-handling station; exact mounting arrangement not specified | Not specified | Roller-top platform for die and mould movement | Not specified | Not specified | Press shops, tool rooms, die changing, mould handling, machine loading and unloading | Roller surface facilitates horizontal movement of dies and moulds; 500 mm lowered height supports low-level handling operations |
| 4 | Semi Electric Mobile Scissor Lift – 1000 kg | 1000 kg (1 tonne) | 900 × 600 × 50 mm* | 900 mm | Not specified | Mobile; manually repositioned | Battery-powered electric lifting; 12 V Exide battery | Compact platform | Nylon wheels | 12 V battery charger; control arrangement not specified | Workshops, production facilities, maintenance, localized material positioning | Combines manual transportation with electrically powered lifting; suitable where mobility and reduced manual lifting effort are required |
| 5 | Mobile Scissor Lift – 800 kg | 800 kg | 1200 × 600 mm | 1500 mm | Not specified | Mobile, wheeled unit | Not specified | Rectangular platform | 2 fixed wheels + 2 swivel wheels | Not specified | Maintenance, installation, workshops, indoor material handling and elevated access | Four-wheel arrangement supports repositioning and steering; 1500 mm lifting height provides elevated access for light-duty operations |
| 6 | Mobile Scissor Lift – 1500 kg | 1500 kg (1.5 tonnes) | 1300 × 1300 mm | 1200 mm | Not specified | Mobile, repositionable | Power pack; phase configuration specified as three-phase | Wide, square platform | Nylon wheels | Three-phase control panel | Heavy material handling, production areas, workshops, equipment positioning | Higher rated capacity than the 800 kg model, with a larger square platform for heavier loads requiring repositioning |
| 7 | Floor Mounted Scissor Lift – 1000 kg | 1000 kg (1 tonne) | 1500 × 1200 mm | 1200 mm | 550 mm | Fixed installation directly on the floor | Hydraulic power pack; 1 HP | Rectangular platform with manual lip plate | Not specified | Three-phase control panel | Warehouse loading, dock-height adjustment, repetitive material transfer and production operations | Stationary lifting configuration with a manual lip plate to bridge a loading gap; designed for repeated height adjustment and material transfer |
Note: The supplied 900 × 600 × 50 mm specification for the semi-electric mobile model is reproduced as provided. The meaning of the 50 mm dimension should be confirmed with the manufacturer.
Technical Interpretation and Engineering Considerations
Scissor lift selection requires an assessment of rated load capacity, platform dimensions, lifting travel, installation requirements, drive system, mobility, safety provisions, and operating environment. The following table identifies the engineering significance of each parameter and the additional information required for a complete technical specification.
| Engineering Parameter | Technical Significance | Information Required for a Complete Specification |
|---|---|---|
| Rated Load Capacity | Defines the maximum permitted load under the manufacturer's specified operating conditions. | Safe Working Load (SWL), load distribution limits and any capacity derating. |
| Platform Dimensions | Determines the available load footprint and compatibility with pallets, dies or containers. | Usable platform dimensions, edge clearances and permitted load overhang. |
| Lifting Height | Defines the maximum platform elevation or vertical travel, depending on the manufacturer's terminology. | Confirmation of maximum platform height versus vertical lifting stroke. |
| Lowered Height | Determines the loading level and installation envelope. | Minimum platform height, pit depth or ramp clearance, and installation tolerances. |
| Hydraulic Power Pack | Supplies hydraulic pressure and flow for lifting. | Pump flow, operating pressure, motor rating, cylinder specifications and hydraulic oil grade. |
| Electrical Supply | Determines power requirements and control-system compatibility. | Voltage, frequency, phase, full-load current, protection rating and wiring diagram. |
| Mobility and Wheels | Influences manoeuvrability, stability and floor compatibility. | Wheel diameter, material, load rating, braking arrangement and floor requirements. |
| Platform Configuration | Determines how materials are loaded, positioned and restrained. | Roller type and spacing, lip plate dimensions, guardrails, stops and restraints. |
| Safety System | Protects operators and helps prevent hazardous movement. | Emergency stop, overload protection, maintenance safety props, hose-burst protection and limit switches. |
| Duty Cycle | Determines suitability for intermittent or repetitive production use. | Lifting cycles per hour, continuous operating duration and design life. |
| Operating Environment | Affects reliability, corrosion resistance and equipment service life. | Indoor/outdoor rating, ambient temperature, dust or moisture protection and surface finish specification. |
Important Scissor Lift Specification Notes
| Technical Aspect | Explanation and Considerations |
|---|---|
| Pit-Mounted vs. Floor-Mounted Scissor Lift | Pit-mounted lifts can provide a near-flush lowered platform when the pit and installation are appropriately designed. Floor-mounted lifts are installed directly on the floor and may require a ramp or lip plate to bridge the loading interface. |
| Mobile vs. Semi-Electric Mobile Scissor Lift | The 800 kg and 1500 kg mobile models are described as repositionable units. The 1000 kg semi-electric mobile model explicitly uses a 12 V battery for powered lifting, with manual mobility. |
| Load Capacity and Application Suitability | Rated capacity alone does not establish suitability. Load centre, eccentric loading, platform dimensions, stability, operating conditions and the manufacturer's load chart must also be considered. |
| Electrical and Hydraulic Specifications | Except for the listed 1 HP power packs and specified three-phase controls, motor ratings, hydraulic pressures, cylinder sizes, lifting speeds and electrical protection details have not been provided. |
| Safety and Regulatory Compliance | Applicable machinery safety standards, guarding requirements, inspection procedures and installation requirements should be confirmed with the manufacturer and the relevant local regulations. |
Engineering Recommendation: Before equipment selection, installation or procurement, request the manufacturer's approved technical datasheet for the relevant model. Confirm the rated load, maximum platform elevation, lowered height, lifting time, hydraulic pressure, electrical supply, safety devices, and installation dimensions to ensure compatibility with the intended industrial application.
Features of Scissor Lift
As a Scissor Lift Supplier in Ahmedabad, Contilift Equipments provides different configurations designed to address specific industrial lifting and material handling requirements.
- Different Load Capacities: Our listed scissor lift models are available from 800 Kg to 2000 Kg, allowing users to select a suitable capacity according to the weight of the material.
- Multiple Installation Options: Pit mounted and floor mounted configurations provide alternatives for permanent lifting points based on the available site conditions.
- Mobile Lifting Capability: Mobile and semi-electric mobile scissor lifts allow the equipment to be repositioned between suitable working areas.
- Large Platform Configurations: Platform sizes range from compact 900 × 600 mm configurations to larger 3000 × 2350 mm platforms for handling different material dimensions.
- Controlled Vertical Lifting: The scissor-arm mechanism provides vertical movement for raising materials to the required working level.
- Die Handling Arrangement: The Die Roller Scissor Lift incorporates a roller-top platform for suitable die and mould handling applications.
- Battery-Assisted Operation: The Semi Electric Mobile Scissor Lift incorporates a 12V battery and charger for powered lifting while retaining mobile functionality.
- Industrial Power Configuration: Selected models are equipped with 1 HP or three-phase power arrangements according to their lifting requirements.
Benefits of Scissor Lift
Different Contilift Scissor Lift configurations can provide practical advantages for material handling, lifting, positioning, and transfer operations.
| Benefit Area | Scissor Lift Feature | Practical Advantage |
|---|---|---|
| Material Handling | Vertical lifting platform | Simplifies movement between working levels |
| Load Capacity | Up to 2000 Kg | Supports heavy industrial loads |
| Installation | Pit and floor mounted options | Suitable for different site arrangements |
| Mobility | Mobile configurations | Allows repositioning where required |
| Die Handling | Roller platform | Facilitates die and mould movement |
| Platform Options | Different platform sizes | Accommodates various material dimensions |
| Reduced Manual Handling | Powered lifting | Reduces physical lifting effort |
| Material Transfer | Controlled height adjustment | Supports loading and unloading operations |
Applications of Scissor Lift
Contilift Scissor Lifts can be used across different industrial applications where controlled vertical lifting and material positioning are required.
- Manufacturing and Production: Scissor lifts can be used for material positioning, machine feeding, assembly operations, component handling, and transferring materials between different working levels.
- Warehousing and Logistics: Pit Mounted and Floor Mounted Scissor Lifts can support pallet handling, loading, unloading, dock-level transfer, and movement of materials between floor levels.
- Press Shops and Die Handling: Die Roller Scissor Lifts are suitable for positioning and handling dies and moulds during machine loading, unloading, and die-changing activities.
- Engineering and Tool Rooms: Die Roller and Mobile Scissor Lifts can assist with tooling movement, component positioning, machine servicing, and material handling.
- Maintenance and Workshops: Mobile and Semi Electric Mobile Scissor Lifts can be used for maintenance, installation, servicing, and lifting tasks where repositioning may be required.
- Loading and Unloading Areas: Pit Mounted and Floor Mounted Scissor Lifts can help raise and lower materials at loading points and transfer areas.
- Industrial Material Transfer: Scissor lifts can be integrated into industrial workflows for moving materials vertically between different working levels.
Contilift Equipments provides Scissor Lifts in Ahmedabad for industrial material handling, material transfer, loading and unloading, die handling, maintenance, and height adjustment applications. Our range includes Pit Mounted Scissor Lift, Die Roller Scissor Lift, Semi Electric Mobile Scissor Lift, Mobile Scissor Lift, and Floor Mounted Scissor Lift.
With capacities ranging from 800 Kg to 2000 Kg across the listed models, different platform sizes, lifting heights, installation arrangements, and mobility options are available to suit specific industrial requirements.
Whether you require a 2000 Kg Pit Mounted Scissor Lift, 1000 Kg Die Roller Scissor Lift, 1000 Kg Semi Electric Mobile Scissor Lift, 800 Kg Mobile Scissor Lift, 1500 Kg Mobile Scissor Lift, 1000 Kg Floor Mounted Scissor Lift, or 1000 Kg Pit Mounted Scissor Lift, Contilift Equipments can help you identify a suitable configuration based on your application.
Looking for a Scissor Lift in Ahmedabad? Contact Contilift Equipments for assistance with capacity, lifting height, platform size, installation type, and application requirements.
FAQ’s
A Scissor Lift is a vertical lifting system that uses linked scissor arms to raise and lower a platform. Industrial scissor lifts are used for material handling, loading, unloading, positioning, die handling, maintenance, and transferring materials between different working levels.
Contilift Equipments provides Pit Mounted Scissor Lift, Die Roller Scissor Lift, Semi Electric Mobile Scissor Lift, Mobile Scissor Lift, and Floor Mounted Scissor Lift configurations.
The listed models have capacities ranging from 800 Kg to 2000 Kg. The required capacity should be selected according to the maximum weight and dimensions of the material being handled.
A Pit Mounted Scissor Lift or Floor Mounted Scissor Lift can be considered for loading and material transfer applications. The appropriate configuration depends on the required capacity, platform dimensions, lifting height, and site arrangement.
A Die Roller Scissor Lift is used for die and mould handling applications. The roller-top platform assists in moving heavy dies during loading, unloading, positioning, and die-changing operations.
A Semi Electric Mobile Scissor Lift combines mobile movement with electrically powered lifting. It is suitable for applications where the lift needs to be repositioned within a facility while reducing manual lifting effort.
A Mobile Scissor Lift is designed to be repositioned between suitable work areas, whereas a Floor Mounted Scissor Lift is installed permanently at a designated location. The selection depends on whether mobility is required for the application.
Consider the maximum load, lifting height, platform size, lowered height, installation arrangement, mobility requirement, power supply, operating frequency, and available space. The dimensions and method of loading the material should also be considered.
Scissor lift configurations can be evaluated according to application requirements such as load capacity, lifting height, platform dimensions, installation arrangement, control requirements, and material handling conditions.
